Specifications of Renault Trafic / Opel/Vauxhall Vivaro / Fiat Talento / Nissan NV300 Van '2014

	Fiat Talento Van	Nissan NV300 Van	Opel Vivaro Van	Renault Trafic Van	Vauxhall Vivaro Panel Van

	2016–21	2016–20	2014–19	2014–19	2014–19
basic
steering wheel location			at left		at right
doors counts			5		5
number of places
total			3		3
design			bearing body		bearing body
geometry
dimensions
length			4,998 mm		4,998 mm
width			1,956 mm		1,956 mm
width, including mirrors			2,283 mm		2,283 mm
height			1,971 mm		1,971 mm
wheel base			3,098 mm		3,098 mm
track
front			1,615 mm		1,615 mm
rear			1,628 mm		1,628 mm
ground clearance
standard			160 mm		160 mm
air resistance
frontal			0.352		0.352
weight
curb			1,800 kg		1,661 kg
full			2,800 kg		2,900 kg
engine
name			1.6 CDTi ecoFLEX LWX (Renault R9M 413/H4)		1.6 CDTi LWX (Renault R9M408)
type			Piston		Piston
location			at front, transversely		at front, transversely
supply system			injector		injector
block material			cast iron		cast iron
cylinders/valves			l4/4		l4/4
cylinder diameter			80.0 mm		80.0 mm
stroke			80.00 mm		80.00 mm
volume			1,598 cc		1,598 cc
power
power			95 hp		90 hp
in the range from			3,500 rpm		3,500 rpm
in the range to			3,500 rpm		3,500 rpm
torque
torque			260 Nm		260 Nm
in the range from			1,500 rpm		1,500 rpm
in the range to			1,500 rpm		1,500 rpm
compression ratio			15.40		15.40
fuel			diesel		diesel
turbo			yes		yes
cooling			liquid		liquid
Gas distribution mechanism			DOHC		DOHC
transmission
drive unit			front-wheel drive		front-wheel drive
gearbox			Manual 6 (Renault PF6)		Manual 6 (Renault PF6)
suspension and steering
front suspension
elastic element type			coil spring		coil spring
type guide vanes			independent		independent
shock absorbers
availability			yes		yes
rear suspension
elastic element type			coil spring		coil spring
type guide vanes			independent multi-link		independent multi-link
shock absorbers
availability			yes		yes
steering type			Реечного типа с гидроусилителем		Реечного типа с гидроусилителем
electric
onboard voltage			12 V
dynamic properties
max speed			153.0 km/h		153.0 km/h
acceleration to 100 km/h			15.4 s		15.9 s
other specs
fuel tank capacity			80		80
boot volume			5,200 l		5,200 l
fuel consumption
EU 93/116/EC
urban			7.2 l/100km		7.8 l/100km
extra urban			5.6 l/100km		5.7 l/100km
combined			6.1 l/100km		6.5 l/100km
"start-stop" system			yes		no
capacity			1,000 kg		1,239 kg
towing weight			2,000 kg		2,000 kg
spread
wall-to-wall			12.4 m		12.4 m
curb-to-curb			11.8 m		11.8 m
turns of steering wheel			3.2
brake system
ABS			yes		yes
front brakes
type			disc		disc
diameter			296 mm		296 mm
thickness			28 mm		28 mm
material			metal		metal
ventilated			yes		yes
rear brakes
type			disc		disc
diameter			280 mm		280 mm
thickness			12 mm		12 mm
material			metal		metal
ventilated			no		yes
emissions			160 CO2 g/km		170 CO2 g/km
emission standard			Euro 6		Euro 5
wheels and tyres
rims material			steel
front			6.0J × 16 205/65 R16
rear			6.0J × 16 205/65 R16
production place			Лутон (Великобритания)		Лутон (Великобритания)
