Wheeled dumpers

The first 100% electric 6-tonne dumper in the world.

• Total operating weight – 5325 kg (11.740 lbs);
• Rated storage capacity – 75 kWh;
• Power supply – 32A 380V three phase (22kW);
• Battery runtime – 8 hrs (depending on the application time);
• Skip type – Swivel;
• Payload – 6000 kg (13,228 lbs);
• Maximum skip capacity (Heaped) – 3085 l (815 US gal);
• Transmission – Automatic, with electric motor via gearbox to both axles;
• Travel speed – 25kph (15.5mph);
• Operator environment – ROPS / FOPS Cab;
• Overall width – 2211 mm (7’3’’);
• Overall length – 4711 mm (15’5’’);
• Overall height – 2875 mm (9’5’’);
• Dumping height, skip tipped – 1126 mm (3’8’’).

The machine is powered by four maintenance-free lithium-ion batteries with a system voltage of 48 V and a total capacity of 22 kWh. The battery pack drives two highly efficient electric motors (one for traction, one for the hydraulic services) giving the operator the control and manoeuvrability expected from a Thwaites dumper.

The Thwaites electric wheel dumper with 180° rotatable high dump bucket (Hi-Swivel) is designed with performance, safety and the environment in mind. Charging is possible via a standard 230 V socket or with an external fast charger, ensuring maximum flexibility on the construction site.

Each dumper is equipped as standard with:

• SAHR handbrake (spring-assisted with hydraulic release);
• ROPS safety roll bar;
• Tow bar;
• LED beacon;
• Full LED Road lighting including daytime running lights;
• Acoustic reversing alarm.

The machine is powered by four maintenance-free lithium-ion batteries with a system voltage of 48 V and a total capacity of 22 kWh.

Two high-efficiency electric motors – one for the drive and one for the hydraulic functions – provide precise control, excellent manoeuvrability and performance that fully match the quality and reliability Thwaites is known for.

Charging is possible via a standard 230 V socket or with an external fast charger, ensuring maximum flexibility on the construction site.

Each dumper is equipped as standard with:

• SAHR handbrake (spring-assisted with hydraulic release);
• ROPS safety roll bar;
• Tow bar;
• LED beacon;
• Full LED Road lighting including daytime running lights;
• Acoustic reversing alarm.

ROPS+ is an extension of the Roll Over Protection System (ROPS). Made from the same high-tensile steel, the wrap-around design places the operator in the optimum position to minimise risk, should a machine roll over occur.

Fully electric dumper with special stainless steel bin for a gelatin plant.

Самосвал с трехсторонним опрокидыванием для транспортировки сыпучего материала любого вида, где условия передвижения не допускают применения более крупных единиц или их применение является неэкономичным. Полезная масса - 2100 кг при загружаемом объеме около 1.1 м³. Сыпучий материал может выбрасываться по выбору влево, вправо или назад.
